HALO
| Featured | ||
 |
Model | HALO |
 |
SP | 8SPD |
 |
Size | 14inch(C-T) |
 |
Color | Green, Black, White |
| Specifications | ||
|---|---|---|
 |
Motor | XOFO SOFD-100 36V 250W(Rear) |
 |
Display | 5 Speed PAS |
 |
Battery | LI-ION BATTERY 36V 14Ah |
 |
Frame | 20*14'' ALLOY 6061 |
 |
Fork | SAGA 20'' ALLOY FORK |
 |
Head Parts | SAGA Inetegrated 1-1/8" |
 |
B.B Parts | NECO B910 Cartridge Type |
 |
S./Pin | SAGA Alloy |
 |
Shifter | SHIMANO ALTUS 8SPD |
 |
F/Derailleur | NIL |
 |
R/Derailleur | SHIMANO ALTUS 8SPD |
 |
C/Wheel | SAGA WINGFOOT 53T |
 |
Freewheel | DNP 13-32T |
 |
Chain | TAYA TB600 |
 |
Rim | 20'' Alloy Double wall 24H |
 |
Hub | JOYTECH Alloy Black 24H(Front) |
 |
Spokes | Steel ED Black |
 |
Tire | KENDA 20*1.5 |
 |
Saddle | SAGA |
 |
Stem | SAGA Alloy |
 |
H/BAR | SAGA Alloy |
 |
Seatpost | SAGA Alloy |
 |
Brake | SHIMANO W/160mm Rotor |
|
B/Lever | PROMAX |
 |
Weight | 18.9kg |
| Frame size | Top tube(A) | Head tube length(B) | Fork length(C) | Head tube angle(D) | Bottom bracket drop(E) | Chain stays(F) | Seat tube angle(G) | Seat tube(H) |
| 14" | 590mm | 105mm | 300mm | 73° | 40mm | 406mm | 82° | 356mm |
